Manufacturer
LSI Logic
Brand
Broadcom
Product Line
Broadcom MegaRAID
Model
9560-8i
Packaged Quantity
1
General
Product Type
Storage controller (RAID)
Storage Controller
Form Factor
Plug-in card
Host Bus
PCIe 4.0 x8
Interface
SATA 6Gb/s / SAS 12Gb/s / PCIe 4.0 (NVMe)
Channel Qty
8
Supported Devices
Disk array (RAID)
Max Storage Devices Qty
240
Buffer Size
4 GB
RAID Level
JBOD, RAID 0, RAID 1, RAID 10, RAID 5, RAID 50, RAID 6, RAID 60
Interface Provided
Interfaces
1 x SATA 6Gb/s / SAS 12Gb/s / PCIe 4.0 (NVMe) – Slim SAS (SFF-8654) (internal)
Power Device
Power Consumption Operational
9.64 watt
System Requirements
OS Required
CentOS, Citrix XenServer, Debian Linux, FreeBSD, Linux Fedora, Microsoft Windows, Oracle Enterprise Linux, Red Hat Linux, SuSe Linux, Ubuntu, VMware ESXi, VMware vSphere (ESXi)
Miscellaneous
Color Category
Black, Green, Silver
MTBF
3,000,000 Hours
Compliant Standards
AS/NZS CISPR 22, CNS 13438, EN 60950, EN55022, EN55024, FCC CFR47 Part 15 B, FCC Class B certified, ICES-003 Class B, IEC 60950, RoHS, UL 60950, VCCI V-3, WEEE
Features
Tri-Mode SerDes technology
