Manufacturer: Dell
Product Type: Expansion Module
Technical Information
Switching capacity: 48 Gbps
Forwarding rate: 36 million packets per second
MAC address table size: 8K entries
VLANs: Up to 256 VLANs
Quality of Service (QoS): Yes
Jumbo frames: Up to 9K bytes
Environmental Specifications
Operating temperature: 32°F to 113°F (0°C to 45°C)
Storage temperature: -40°F to 158°F (-40°C to 70°C)
Operating humidity: 10% to 90% non-condensing
Storage humidity: 5% to 95% non-condensing
Power Specifications
Power consumption: 22.5W
Power input: 12V DC
Power supply: External AC adapter (100-240V AC, 50-60Hz)
Dimensions & Weight
Height: 1.1 inch
Width: 2.2 inch
Depth: 9.5 inch
Weight: 3 LBS
