$690.00
The Dell PERC H840 is a high-performance RAID controller designed to provide enterprise-level storage management and scalability. Here are some of the key performance and scalability features of the H840.
Performance: The H840 supports 12GB/s SAS and is designed to deliver fast storage performance, with high I/O throughput and low latency. It can support multiple drives in a variety of RAID configurations, including 0, 1, 5, 6, 10, 50, 60 and more.
Manufacturer: Dell
Part Number or SKU# 405-AANN
Device Type: Raid Controller
Interface: PCI Express 3.1 (8 lanes)
Cache Memory: 2GB DDR4
Max Cache Memory: 4GB DDR4
Max Number of Physical Devices Supported: 1024
Supported Drive Types: SAS, SATA, NVMe
RAID Levels Supported: 0, 1, 5, 6, 10, 50, 60
Battery Backup: Yes (optional)
Max Number of Host Connections: 2
SAS Ports: 4 internal, 4 external
Form Factor: Low profile
Power Consumption: 20W
