Manufacturer
Lenovo System X
Brand
Lenovo
Product Line
Lenovo ThinkSystem
Model
PM1735 Mainstream
Packaged Quantity
1
Storage
Type
Solid state drive
Hard Drive
Hard Drive Type
Internal hard drive
Form Factor
PCIe card (HHHL)
Form Factor (metric)
PCIe card (HHHL)
Form Factor (Short)
PCIe card
Form Factor (Short) (metric)
PCIe card
Storage Interface
PCI Express 4.0 x8 (NVMe)
Interface
PCI Express 4.0 x8 (NVMe)
Capacity
3.2 TB
Average Latency
25 microsecond
Internal Data Rate
8000 MBps
Internal Data Rate (Write)
3800 MBps
4KB Random Read
1500000 IOPS
4KB Random Write
250000 IOPS
Non-Recoverable Errors
1 per 10^17
Drive Writes Per Day (DWPD)
3
SSD Endurance
17.52 PB
Features
Advanced ECC Engine, End-to-end data protection, Power loss data protection, V-NAND Technology
Compliant Standards
S.M.A.R.T.
Interface Provided
Interfaces
1 x PCI Express 4.0 x8
Bay Required
Compatible Bay
PCIe card (HHHL)
Software
Type
None
Power Consumption
Power Consumption
19 Watt (read), 22 Watt (write)
Miscellaneous
Included Hard Drive Accessories
3U bracket
MTBF
2,000,000 Hours
Compliant Standards
BSMI, CB, cUL, FCC, IC, KC, RCM, TUV GS, VCCI
Dimensions & Weight
Depth
6.6 inch
Height
2.7 inch
Weight
10.93 ounce
Service & Support
Type
1-year warranty
Service & Support Details
Service & Support
Limited warranty – replacement – 1 year
Shock & Vibration Tolerance
Shock Acceleration (Operating)
1500 gram
Shock Duration (Operating)
0.5 ms
Vibration Acceleration (Operating)
20 gram
Vibration Frequency Range (Operating)
10-2000 Hz
Environmental Parameters
Min Operating Temperature
32 degree Fahrenheit
Max Operating Temperature
158 degree Fahrenheit
Min Storage Temperature
-40 degree Fahrenheit
Max Storage Temperature
185 degree Fahrenheit
Humidity Range Operating
5 – 95% (non-condensing)
