GENERAL INFORMATION:
Manufacturer: Hewlett Packard
Manufacturer Part Number: 642120-001
Product Name: Proliant Dl380p G8 – 2-Way 2u Rack Mount (Base Model)
PROCESSOR & CHIPSET:
Processor Type: Intel Xeon E5-2620/ 2.00 Ghz
Multi-Core Technology: Hexa-Core (6 Core)
Quickpath Interconnect: 7.20 Gt/S
64 Bit Computing: Yes
Installed Qty: 1
Max Supported Qty: 2
Upgradability: Upgradable
Chipset Model: Intel C600
CACHE MEMORY:
Type: L3 Cache
Installed Size: 15 MB
Cache Per Processor: 15 MB
MEMORY:
Installed Size: 16 Gb / 768 Gb (Max)
Technology: Ddr3 Sdram
Memory Speed: 1333 Mhz
Memory Specifications Compliance: Pc3-10600
Form Factor: Dimm 240-Pin
Number Of Total Memory Slots: 24 Ddr3 Slots
Features: Registered
Configuration Features: 4 X 4 Gb
RAM SUPPORTED:
PC3-12800 – 384 GB – Registered
PC3-10600 – 768 GB
PC3-10600 – 128 GB – Unbuffered – Advanced Ecc
STORAGE & STORAGE CONTROLLERS:
Hard Drive: None
Optical Drive Type: None
Type : Card Reader
Supported Flash Memory Cards : Sd Memory Card
Storage Controller Type: 1 X Raid – Plug-In Card – Pci Express 3.0 X8
Controller Interface Type: Serial Ata-300 / Sas 2.0
Storage Controller Name: Smart Array P420i
Raid Level: Raid 0 Raid 1 Raid 5 Raid 10 Raid 50
Buffer Size: 1 Gb
DISPLAY & GRAPHICS:
Graphics Type: Integrated
Graphics Controller Model: Matrox G200
Video Interfaces : Vga
NETWORK & COMMUNICATION:
Type : Integrated
Ethernet Controller : 1gb 4-Port 331flr Adapter
Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller : Integrated Lights-Out 4
Features : Wake On Lan (Wol), Pxe Support
Compliant Standards : Ieee 802.3, Ieee 802.3u, Ieee 802.1q, Ieee 802.3ab, Ieee 802.1p, Ieee 802.3ad (Lacp)
POWER DESCRIPTION:
Device Type: Power Supply Hot Plug
Power Redundancy: Yes
Power Redundancy Scheme: 1+1
Installed Qty: 1
Max Supported Qty: 2
Voltage Required: Ac 120/220 V
Power Provided: 460 Watt.
