GENERAL INFORMATION :
Manufacturer : Hewlett Packard
Manufacturer Part Number : 669256-B21
Product Name : Proliant Dl380e Gen8 2u Rack Mount Cto
PROCESSOR & CHIPSET :
Processor Type : Intel Xeon
Sockets Supported : 2 X Hp Smart Socket Lga1356
64-Bit Computing : Yes
Installed Qty : None
Max Supported Qty : 2
Upgradability : Upgradable
Chipset Type : Intel C600
MEMORY :
Installed Size : None
Maximum Size : 384 Gb
Technology : Ddr3 Sdram
Form Factor : Dimm 240-Pin
Total Memory Slots : 12 Ddr3 Slots
STORAGE & STORAGE CONTROLLER :
Hard Drive : None, Up To 25-Sff Drive Cage
Storage Controller Type : 1 X Raid – Plug-In Card – Pci Express 3.0 X8
Controller Interface Type : Serial SAta-300 / Sas 2.0
Storage Controller Name : Hp Dynamic Smart Array B120i With Zero Memory
CARD READER :
Card Reader Type : Card Reader
Supported Flash Memory Cards : Sd Memory Card
DISPLAY & GRAPHICS CONTROLLERS :
Graphics Controller Type : Integrated
Graphics Processor :Matrox G200
NETWORK & COMMUNICATION :
Networking : Network Adapter – Pci Express 2.0 X2 – Integrated
Ethernet Ports : 4 X Gigabit Ethernet
Ethernet Controller(S) : Hp Ethernet 1gb 4-Port 366i Adapter
Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller : Integrated Lights-Out 4
Features : Wake On Lan (Wol), Pxe Support
POWER DEVICE :
Device Type : Power Supply – Hot-Plug
Power Redundancy : Optional
Power Redundancy Scheme : 1+1 (With Optional Power Supply)
Installed Qty : 0
Max Supported Qty : 2
Voltage Required : Ac 120/230 V ( 50/60 Hz )
