Processor
Clock Speed :2.1 GHz
Installed Qty :1
Manufacturer :Intel
Max Supported Qty :2
Max Turbo Speed :3.2 GHz
Number of Cores :16-core
Processor Main Features :Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Virtualization Technology
Processor Number :4216
Server Scalability :2-way
Type :Xeon Bronze
Audio Input
Type :None
Cache Memory
Installed Size :22 MB
Installed Size :22
Per Processor Size :22 MB
Per Processor Size :22
Display
Type :None.
Header
Brand :Lenovo
Country Kits :North America
Manufacturer :Lenovo System X
Model :7X06
Packaged Quantity :1
Product Line :Lenovo ThinkSystem SR650
Interface Provided
Connector Type :RJ-45
Qty :1
Type :Management
Location :1 front, 1 rear
Qty :2
Type :VGA
Location :1 front, 2 rear
Qty :3
Type :USB 3.0
Location :1 in front
Type :USB 2.0
Mainboard
Chipset Type :Intel C624
Miscellaneous
Color Category :Black
Compliant Standards :AS/NZS CISPR 22, BSMI CNS 13438 Class A, BSMI CNS 14336-1, CB, EK1-ITB2000, EN 60950-1, EN55022 Class A, EN55024, EN61000-3-2, EN61000-3-3, FCC Part 15 A, GB 17625.1, GB 4943.1, GB 9254 Class A, GOST ME01, GOST-R 51317.3.2, GOST-R 51317.3.3, GOST-R 51318.22, GOST-R 51318.24, ICES-003 Class A, IEC60950-1, KN22 Class A, KN24, NMB-3 Class A, NOM-019, RoHS, TUV GS, UL/CSA60950-1, VCCI Class A
Height (Rack Units) :2
Included Accessories :Tool-less rail kit
Networking
Remote Management Controller :XClarity Controller (XCC) Enterprise
OS Provided
Type :No operating system
Power Device
80 PLUS Certification :80 PLUS Platinum
Frequency Required :50/60 Hz
Installed Qty :1
Max Supported Qty :2
Nominal Voltage :AC 120/230 V
Power Provided :750 Watt
Power Redundancy :Optional
Power Redundancy Scheme :1+1 (with optional power supply)
Type :Power supply – hot-plug
Printer
Type :None
RAM
Configuration Features :1 x 32 GB
Data Integrity Check :ECC
Empty Slots :23
Features :Demand Scrubbing, Memory Mirroring, Memory Sparing, Mixing of different types of memory modules is not supported, Patrol Scrubbing, Registered, Slots 13 – 24 are available in two-processor configuration only, Supports Intel Optane DC Persistent Memory (DCPMM)
Form Factor :DIMM 288-pin
Installed Size :32 GB
Installed Size :32
Max Supported Size :768 GB
Max Supported Size :768
Memory Speed :2400 MHz
Rated Memory Speed :2666 MHz
Slots Qty :24
Technology :DDR4 SDRAM
Slot Provided
Free Qty :1
Total Qty :1
Optical Storage (2nd)
Drive Type :No optical drive
Type :None
Storage Controller
Type :None
Storage Controller (2nd)
Type :None
Storage Removable
Type :None
System
Embedded Security :Trusted Platform Module (TPM 1.2 and TPM 2.0)
Hard Drive Capacity :0 GB
Type :Server
Video Output
Graphics Processor Series :Matrox G200
Graphics Processor Vendor :Matrox G200
Video Interfaces :VGA
Dimensions & Weight
Depth :28.3 in
Height :3.4 in
Weight :41.89 lbs
Width :17.5 in
