9200-8E Lsi Logic 6Gb 8Port PCI-Express Sas/Sata Host Bus Adapter Controller

9200-8E Lsi Logic 6Gb 8Port PCI-Express Sas/Sata Host Bus Adapter Controller

$60.00

The 9200-8E LSI Logic 6Gb 8Port PCI-Express SAS/SATA Host Bus Adapter Controller is a device that allows you to connect up to eight SAS or SATA hard drives to your computer. The device is designed for high-speed data transfer and is compatible with a wide range of operating systems.

The 9200-8E LSI Logic 6Gb 8Port PCI-Express SAS/SATA Host Bus Adapter Controller is a high-performance storage controller that provides a fast and reliable connection between your computer and up to eight SAS or SATA hard drives. The device is designed to work with a wide range of operating systems, including Windows, Linux, and VMware.

9200-8E Lsi Logic 6Gb 8Port PCI-Express Sas/Sata Host Bus Adapter Controller
$60.00
Contact Us

Manufacturer: Lsi Logic

Part Number or SKU# 9200-8E

Product Type: Controller

Product Name: SAS-SATA

Storage Connectivity Data Transfer Rates

8 Ports 6gb/s Sas 2.0 Compliant

Host Bus : X8 Lane, Pci Express 2.0 Compliant

Pci Data Burst Transfer Rates : Half Duplex

x8, Pcie, 4000 Mb/s

Dimensions

+12v ±10%

Low Profile (2. 6″ X 6.6″)

Cable Support : Passive Copper

Pci Card Type : 3.3 V Add-in Card

Operating Voltage : +12v +/-8% 3.3v +/-8%

Pci Power (nominal) : 8 W Typical (airflow Min 200 Lfm)

Device Support : 512 Non-raid Sas/sata Devices

SKU: 9200-8E Category: Tag:
