Manufacturer :APC
Brand :APC
Product Line :APC Back-UPS
Model :650
Country Kits :United States
Packaged Quantity :1
General
Subcategory :UPS
Product Type :UPS
Networking
Remote Management Interface :USB
Interface Provided
Interfaces :1 x management (USB) – 4 pin USB Type B
Cable Details
Cables Included :Power cable – integrated – 5 ft, USB cable
Power Device
Form Factor :External
Voltage Provided :AC 120 volt
Frequency Provided :60 hertz
Frequency Provided Margin :± 3Hz
UPS Output Waveform :Stepped approximation to a sinewave
Power Provided :390 watt
Power Capacity (VA) :650 volt ampere per kilogram 650VA
Max Electric Current :12 ampere
Voltage Required :AC 120 volt
Input Voltage Range :AC 90 – 140 V
Frequency Required :60 hertz
Frequency Required Margin :± 3Hz
Input Connector Type :Power NEMA 5-15P
Input Connector Qty :1
Output Connector Type :Power NEMA 5-15R
Output Connector Qty :8
Surge Suppression :Yes
Switchover Time :8 millisecond
Surge Energy Rating :340 joules
Circuit Protection :Circuit breaker
Power Device Features :LED indicators, Cold-start function, Automatic self-test, Audible alarm, Predicitive failure notification
Power Output Connectors Details
Power Output Connectors Details :4 x power NEMA 5-15R (surge), 4 x power NEMA 5-15R (UPS and surge)
Dataline Surge Protection
Dataline Surge Protection :Network – RJ-45
Battery
Run Time (Up To) :3.3 minute (time unit)
Load Type :At full load
Recharge Time :24 Hours
Run Time Details
Run Time (Up To) :5.9 min at 300 Watts, 12 min at half load, 29.2 min at 100 Watts, 11.6 min at 200 Watts, 3.3 min at full load
UPS
Batteries Qty :1
Battery Technology :Lead acid
Miscellaneous
Color :Black
Color Category :Black
Equipment Protection Value :75000 US Dollars
Compliant Standards :FCC Part 15 Class B, TUV C, UL 1778, NOM, FCC Part 68, CSA C22.2 No. 107.1, RoHS, REACH
Environmental Standards
ENERGY STAR :Yes
Dimensions & Weight
Width :7.1 inch
Depth :11.9 inch
Height :3.5 inch
Weight :13.67 lbs
Dimensions & Weight (Shipping)
Shipping Width :9.3 inch
Shipping Depth :15.5 inch
Shipping Height :5 inch
Shipping Weight :15.43 lbs
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Humidity Range Operating :5 – 95%
Sound Emission :45 dBA
