Manufacturer :APC
Brand :APC
Product Line :APC Back-UPS Connect
Model :50
Packaged Quantity :1
General
Subcategory :UPS
Product Type :UPS
Cable Details
Cables Included :Power cable – integrated – 5 ft
Power Device
Form Factor :External
Voltage Provided :AC 120 volt
Frequency Provided :50/60 hertz
Frequency Provided Margin :± 3Hz
UPS Output Waveform :Stepped approximation to a sinewave
Power Provided :50 watt
Power Capacity (VA) :84 volt ampere per kilogram
Voltage Required :AC 120 volt
Input Voltage Range :AC 92 – 139 V
Frequency Required :50/60 hertz
Frequency Required Margin :± 3Hz
Input Connector Type :Power NEMA 5-15P
Input Connector Qty :1
Output Connector Qty :2
Surge Energy Rating :340 joules
Circuit Protection :Circuit breaker
Power Device Features :LED indicators, Audible alarm, Automatic self-test
Power Output Connectors Details
Power Output Connectors Details :1 x 4 pin mini-USB Type A – 2.4 A, 2 x 4 pin USB Type A – 1 A, 2 x power NEMA 5-15
Battery
Run Time (Up To) :33.2 minute (time unit)
Load Type :At full load
Recharge Time :2.5 Hours
Run Time Details
Run Time (Up To) :33.2 min at full load, 63 min at half load
UPS
Battery Technology :Lithium ion
Miscellaneous
Color :White
Color Category :White
Compliant Standards :EN 61000-3-2, EN 61000-4-3, EN 61000-4-8, EN 61000-4-2, FCC Part 15 B, ICES-003, RoHS, CEC, UN38.3, EN55022 Class A, REACH, EN55024, cTUVus, EN 61000-3-3
Dimensions & Weight
Width :7.7 inch
Depth :7 inch
Height :2.1 inch
Weight :2.87 lbs
Dimensions & Weight (Shipping)
Shipping Width :13.4 inch
Shipping Depth :9.2 inch
Shipping Height :2.6 inch
Shipping Weight :3.97 lbs
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Humidity Range Operating :0 – 95% (non-condensing)
Sound Emission :32 dBA
