Manufacturer :APC
Brand :APC
Product Line :APC Back-UPS
Country Kits :United States
Packaged Quantity :1
Output
Max Configurable Power (Watts)
255Watts / 450VA
Output Frequency (sync to mains)
50/60Hz +/- 3 Hz
Topology
Standby
Waveform type
Square wave
Transfer Time
6ms typical : 10ms maximum
Input
Input frequency
50/60 Hz +/- 3 Hz (auto sensing)
Input voltage range for main operations 88 – 139V
Number of Power Cords 1
Batteries & Runtime
Battery type
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Typical recharge time 8hour(s)
Expected Battery Life (years) 3 – 5
Battery Charge Power (Watts) 6Watts
Battery Volt-Amp-Hour Capacity 47
Runtime
View Runtime Graph
View Runtime Chart
Efficiency
View Efficiency Graph
Communications & Management
Control panel
LED Status display with On Line : On Battery
Audible Alarm
Alarm when on battery : distinctive low battery alarm
Surge Protection and Filtering
Surge energy rating
180Joules
Data Line Protection
Physical
Maximum Height
5.52inches (140MM, 14.0CM)
Maximum Width
9.98inches (253MM, 25.3CM)
Maximum Depth
4.13inches (105MM, 10.5CM)
Net Weight
5.73lbs. (2.6KG)
Shipping weight
6.61lbs. (3.0KG)
Shipping Height
8.66inches (220MM, 22.0CM)
Shipping Width
12.4inches (315MM, 31.5CM)
Shipping Depth
5.51inches (140MM, 14.0CM)
Color Black
Master Carton Units 2.0
Master Carton Weight
14.33lbs. (6.5)
Units per Pallet 96.0
SCC Codes
1073130432937 1
Environmental
Operating Temperature
32 – 104 °F (0 – 40 °C)
Operating Relative Humidity
0 – 95 %
Operating Elevation
0-10000ft (0-3000meters)
Storage Temperature
-20 – 50 °C
Storage Relative Humidity
0 – 95 %
Storage Elevation
0-50000ft (0-15000meters)
