Manufacturer :APC
Brand :APC
Product Line :APC Back-UPS Pro
Model :BR
Packaged Quantity :1
General
Subcategory :UPS
Product Type :UPS
Networking
Remote Management Interface :USB, Serial
Interface Provided
Interfaces :1 x management (RS-232/USB)
Cable Details
Cables Included :Power cable 6 ft
Power Device
Form Factor :External
UPS Technology :Line interactive
Voltage Provided :AC 120 volt
Frequency Provided :60 hertz
Frequency Provided Margin :± 3Hz
UPS Output Waveform :Sinewave
Power Provided :600 watt
Power Capacity (VA) :1000 volt ampere per kilogram 1000VA
Voltage Required :AC 120 volt
Input Voltage Range :AC 88 – 139 V
Frequency Required :60 hertz
Frequency Required Margin :± 3Hz
Input Connector Type :Power NEMA 5-15
Input Connector Qty :1
Output Connector Type :Power NEMA 5-15
Output Connector Qty :10
Surge Suppression :Yes
Surge Energy Rating :1080 joules
Circuit Protection :Circuit breaker
Efficiency :98.8% at 50% Load, 97.9% at 25% Load, 99% at 100% Load, 99% at 75% Load
Power Device Features :Audible alarm, Automatic Voltage Regulation (AVR), LCD display, Automatic self-test
Power Output Connectors Details
Power Output Connectors Details :1 x 4 pin USB Type A, 4 x power NEMA 5-15 (surge), 6 x power NEMA 5-15 (UPS and surge), 1 x 24 pin USB-C
Dataline Surge Protection
Dataline Surge Protection :Coaxial – 1 input line / 1 output line, Network/phone line – RJ-45 – 1 input line / 1 output line
Battery
Run Time (Up To) :3.7 minute (time unit)
Load Type :At full load
Recharge Time :16 Hours
Lead Acid Battery Features :Sealed, Leak-proof, Maintenance free
Run Time Details
Run Time (Up To) :5.4 min at 500 Watts, 3.7 min at full load, 8 min at 400 Watts, 78 min at 50 Watts, 42.9 min at 100 Watts, 20.5 min at 200 Watts, 12.2 min at 300 Watts
UPS
Batteries Qty :1
Battery Technology :Lead acid
Miscellaneous
Color :Black
Color Category :Black
Equipment Protection Value :250000 US Dollars
Compliant Standards :FCC Part 15 C Class B, NOM, TUV GS
Dimensions & Weight
Width :3.9 inch
Depth :14.5 inch
Height :10.2 inch
Weight :22.49 lbs
Dimensions & Weight (Shipping)
Shipping Width :8.8 inch
Shipping Depth :19 inch
Shipping Height :14.1 inch
Shipping Weight :26.01 lbs
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Humidity Range Operating :0 – 95% (non-condensing)
Sound Emission :45 dBA
