Modem
16×4 CableLabs certified DOCSIS 3.0 Modem
Wi-Fi Performance
AC1600 (300 Mbps + 1300 Mbps)
Wi-Fi Bands
Simultaneous Dual Band Wi-Fi – 2.4 & 5 GHz
Ethernet Ports
2 x 10/100/1000 LAN Gigabit Ethernet ports with auto-sensing technology
USB Ports
1 x USB 2.0 port
Coaxial Ports
1 x Coaxial port for cable Internet
Channels
16 x Downstream channels
4 x Upstream channels
Wi-Fi Transmitters/Receivers (Tx/Rx)
2×2 (2.4 GHz) + 3×3 (5 GHz)
Memory
128 MB Flash
256 MB RAM
Security
Wi-Fi Protected Access (WPA/WPA2-PSK) and WEP
Double firewall protection (SPI and NAT firewall)
Denial-of-service (DoS) attack prevention
Push ‘N’ Connect-Easy push button Wi-Fi connections (WPS) connections (WPS)
Wi-Fi Standards
IEEE 802.11 b/g/n 2.4 GHz
IEEE 802.11 a/n/ac 5 GHz
System Requirements
Cable broadband Internet service
Check your cable Internet service provider web site for data speed tier compatibility
Microsoft Windows 7, 8, Vista, XP, 2000, Mac OS, UNIX, or Linux
Microsoft Internet Explorer 5.0, Firefox 2.0, Safari 1.4, or Google Chrome 11.0 browsers or higher
Use laptop with 3×3 450 Mbps adapter like Centrino 6300/5300 for maximum performance
Use with an 802.11ac adapter like NETGEAR A6210 for maximum performance
Dimensions
