Bay Provided
Form Factor :3.5″ LFF
Free Qty :4
Total Qty :4
Cache Memory
Installed Size :15 MB
Installed Size :15
Per Processor Size :15 MB
Per Processor Size :15
Type :L3 cache
Chassis
Form Factor :Rack-mountable
Hot Swap Bays Qty :4 Bays
Manufacturer Form Factor :Rack-mountable
Server Storage Bays :Hot-swap
Server Swappable Drive Form Factor :3.5″
Server Swappable Drive Form Factor (metric) :8.9 cm
Server Swappable Drive Interface :SAS
Dimensions & Weight
Depth :29.8 in
Height :1.7 in
Width :16.9 in
Display
Type :None.
Environmental Parameters
Humidity Range Operating :10 – 90% (non-condensing)
Max Operating Temperature :95 °F
Min Operating Temperature :41 °F
Expansion Bays
Form Factor (metric) :8.9 cm LFF
Type :Hot-swap
Expansion Slots
Type :CPU
Type :DIMM 288-pin
Type :PCIe
Hard Drive
Type :No HDD
Header
Brand :Cisco
Compatibility :PC
Manufacturer :CISCO DS HARDWARE DIRECT
Model :C220 M4
Packaged Quantity :1
Product Line :Cisco Connected Safety and Security UCS
Interface Provided
Connector Type :DB-15
Type :VGA
Connector Type :RJ-45
Type :Serial
Qty :1
Type :KVM
Qty :2
Type :USB 3.0
Type :LAN (Gigabit Ethernet)
Type :Management
Mainboard
Processor Socket :LGA2011-v3 Socket
Miscellaneous
Color Category :Silver
Compliant Standards :ACPI 4.0
Height (Rack Units) :1
Networking
Data Link Protocol :Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet Ports :2 x Gigabit Ethernet
Power Device
Installed Qty :1
Max Supported Qty :2
Power Provided :770 Watt
Power Redundancy :Optional
Power Redundancy Scheme :1+1 (with optional power supply)
Type :Power supply
Printer
Type :None
Processor
Clock Speed :2.4 GHz
Installed Qty :1
Manufacturer :Intel
Max Supported Qty :2
Max Turbo Speed :3.2 GHz
Number of Cores :6-core
Processor Number :E5-2620V3
