Manufacture Part Number
Manufacture : MikroTik
Non-blocking Layer 2 switching capacity
16K host table
IEEE 802.1Q
Supports up to 4K simultaneous VLANs
Port isolation
Port security
Broadcast storm control
Port mirroring of ingress/egress traffic
Rapid Spanning Tree Protocol
Access Control List
MikroTik neighbor discovery
SNMPv1
Web-based GUI
Product Specifications
CPU: 98DX3236A1 800MHz
RAM: 512MB
Storage Type: Flash, 16MB
Switch Chip Model: 98DX3236A1
10/100/1000 Ethernet Ports: 24
SFP+ Cages: 2
Operating System: SwOS/RouterOS (Dual Boot)
Support Input Voltage: 9-30V (jack or passive PoE)
Dimensions: 440 x 144 x 44mm
Operating Temperature: -40°F to 140°F tested (-40 to 60°C)
Max. Power Consumption: 24W
Serial Port: RJ45
