Brand : Infortrend
Manufacturer Part Number : DS4024R2CB00H
Form Factor DS 4024B Gen2
2U 24-bay DS 4016 Gen2
3U 16-bay DS 4024 Gen2
4U 24-bay
Controller Dual redundant controllers
Host Ports Onboard Gb/s ports
8 x 1Gb/s iSCSI ports (4 per controller)
More host options:
Pure options:
16 x 16Gb/s Fibre Channel ports (8 per controller, No Remote Replication support)
16 x 8Gb/s Fibre Channel ports (8 per controller)
16 x 10Gb/s iSCSI ports/ SFP+ (8 per controller)
8 x 10Gb/s iSCSI ports/ RJ-45 (4 per controller)
8 x 12Gb/s SAS ports (4 per controller)
16 x 10Gb/s FCoE ports (8 per controller)
8 x 40Gb/s iSCSI ports/ QSFP (4 per controller)
8 x 56Gb/s Infiniband ports (4 per controller) – for Linux only
Hybrid options(Host board 1 and host board 2):
4 or 8 x 10Gb/s iSCSI ports/ SFP+ and four 16Gb/s Fibre Channel ports
4 or 8 x 10Gb/s iSCSI ports/ SFP+ and eight 8Gb/s Fibre Channel ports
Note: Fibre channel supports point-to-point and switch mode.
Cache Memory Default DDR4 16GB, up to 32GB, 64GB, 128GB or 256GB
Cache Backup Techniques Super Capacitor + Flash module
Maximum Number of Drives Via expansion enclosure: 448
Drive Connectivity 12Gb/s SAS connectivity
Drive Advanced Features S.M.A.R.T. support/ Automatic bad-sector reassignment/ Dedicated bandwidth to each connected drive
Supported Drives 2.5″ SAS SSDs
2.5″ SATA SSDs
2.5″ 10,000 RPM & 15,000 RPM SAS drives
3.5″ 7,200 RPM Nearline SAS drives
Note: MUX board required when using SATA drives for dual controllers
