Dimensions & Weight
Width: 17.5 in
Depth: 27.8 in
Height: 27.8 in
Weight: 203.48 lbs
Environmental Parameters
Min Operating Temperature: 32 °F
Max Operating Temperature: 104 °F
Humidity Range Operating: 5 – 90% (non-condensing)
Min Storage Temperature: -40 °F
Max Storage Temperature: 158 °F
Humidity Range Storage: 5 – 95% (non-condensing)
General
Device Type: Switch – L3 – managed
Enclosure Type: Front to back airflow rack-mountable 16U
Processor: 1 x Intel: 1.73 GHz
RAM: 16 GB
Built-in Devices: Midplane
Expansion / Connectivity
Installed Modules Qty (Max): 4 (installed) / 16 (max)
Power
Power Device: Internal power supply – hot-plug
Installed Qty: 2
Max Supported Qty: 4
Power Redundancy: Yes
Power Redundancy: Scheme 1+1
Power Provided: 4100 Watt
