Manufacturer: Fortinet
Brand: Fortinet
Product Type: Transceiver Module
Form Factor: SFP+
Data Rate (max): 10.5 Gb/s
Distance (max): 80KM
Transmitter: EML
Receiver: APD
Digital Diagnostic: Yes
Connector: Duplex LC
Cable Type: SMF
Wavelength: DWDM C-band
Operating Temperature: 0 to 70°C (32 to 158°F)
Wavelength: 1563.86nm to 1528.77nm
Max Cable Distance: 40km
Optical Components: EML DWDM
DOM Support: Yes
TX Power: 0-4dBm
Receiver Sensitivity: <-23dBm Power budget: 23dB Receiver Overload: -8dBm Power Consumption: <1.8W Commercial Temperature Range: 0 to 70°C (32 to 158°F) Bit Error Ratio (BER): 1E-12 Extinction Ratio :-7.5dB
