Manufacturer Fortinet, Inc
Manufacturer Part Number
Brand Name Fortinet
Product Line Forti Switch
Product Model Rugged-124D
Product Name Forti Switch Rugged-124D Ethernet Switch
Product Type Ethernet Switch
Technical Information−
Network & Communication
Layer Supported 2
Management & Protocols
Manageable Yes
Dimensions in. 17.40 x 13.86 x 1.73
Input voltage range 4457V DC
MAC addresses 8K
Switch power 25.434 W (Maximum)
Heat dissipation 117.49 BTU/h
Operating temperature -40185°F (-4085°C)
EMI Radiated Emission: CISPR 22, EN55022 Class B Conducted Emission: EN55022 Class B
EMS ESD: IEC61000-4-2
Radiated RF (RS): IEC61000-4-3 EFT: IEC61000-4-4
Surge: IEC61000-4-5
Conducted RF (CS): IEC61000-4-6
