Hot-pluggable SFP+ footprint
Supports rate selectable 1.25 Gb/s or 9.95 to 10.3 Gb/s bit rates
Power dissipation < 1 W RoHS-6 compliant (lead-free) Commercial temperature range 0 °C to 70 °C Single 3.3 Vdc power supply Max. link length 300 m on 2000 MHZ-km MMF (SR), 10 km (LR) Uncooled 1310 nm DFB laser (LR) Receiver limiting electrical interface Duplex LC connector Built-in digital diagnostic functions Distance: 400 m Data Rate (max): 10.3 Gb/s Protocol: Optical Gigabit Ethernet Compliant 10 Gigabit Ethernet Compliant Wireless CPRI Compliant Low End Case Temperature (°C): 0 High End Case Temperature (°C): 70 Diagnostics: Digital Transmitter: VCSEL Receiver: PIN Voltage Supply: 3.3 Connector: LC Wavelength: 850nm Band
