Header
Manufacturer :APC
Brand :MGE
Product Line :MGE Galaxy
Model :3500 with 1 Battery Module Expandable to 4
Packaged Quantity :1
General
Subcategory :UPS
Product Type :UPS
Networking
Remote Management Interface :RS-232
Remote Management Protocol :SNMP, HTTP
Expansion Slots
Expansion Slots :1 (total) / 0 (free) x SmartSlot
Interface Provided
Interfaces :1 x management (RS-232)
Cable Details
Cables Included :Serial cable – external
Software
Type :Drivers & Utilities
Power Device
Form Factor :External
UPS Technology :On-line
Voltage Provided :AC 120/208/220 volt
Voltage Provided Margin :± 3%
Frequency Provided :57 – 63 hertz
UPS Output Waveform :Sinewave
Power Provided :8 kilograms per millimetere
Power Capacity (VA) :10000 volt ampere per kilogram
Voltage Required :AC 208 volt
Input Voltage Range :AC 160 – 240 V
Frequency Required :40 – 70 hertz
Input Wiring :3-phase
Input Connector Type :Hardwire 5-wire (3PH + N + G)
Input Connector Qty :1
Output Connector Type :Hardwire 5-wire (3PH + N + G), Terminal block (screw), Hardwire 4-wire (3PH + G)
Output Connector Qty :3
Power Device Features :LCD display, Audible alarm, Built-in maintenance bypass, Built-in static bypass
Power Output Connectors Details
Power Output Connectors Details :1 x hardwire 4-wire (3PH + G), 1 x terminal block (screw), 1 x hardwire 5-wire (3PH + N + G)
Battery
Run Time (Up To) :7 minute (time unit)
Load Type :At full load
Recharge Time :5 Hours
Run Time Details
Run Time (Up To) :7 min at full load
UPS
Expandable Battery :Expandable
Batteries Qty :1
Supported Batteries Qty :4
Battery Technology :Lead acid
Miscellaneous
Included Accessories :Bolt down brackets
Compliant Standards :cUL, ISO 9001, NEMA Type 12, UL 1778, ISO 14001
Features :LCD display
Dimensions & Weight
Width :20.6 inch
Depth :33 inch
Height :58.7 inch
Weight :712.09 lbs
