Header
Manufacturer :APC
Brand :MGE
Product Line :MGE Galaxy
Model :3500 with 2 Battery Modules Expandable to 4
Packaged Quantity :1
General
Subcategory :UPS
Product Type :UPS
Networking
Remote Management Interface :RS-232
Remote Management Protocol :SNMP, HTTP
Expansion Slots
Expansion Slots :1 (total) / 0 (free) x SmartSlot
Interface Provided
Interfaces :1 x management (RS-232)
Cable Details
Cables Included :Serial cable – external
Software
Type :Drivers & Utilities
Power Device
Form Factor :External
UPS Technology :On-line
Voltage Provided :AC 120/208/220 volt
Voltage Provided Margin :± 3%
Frequency Provided :57 – 63 hertz
UPS Output Waveform :Sinewave
Power Provided :8 kilograms per millimetere
Power Capacity (VA) :10000 volt ampere per kilogram
Voltage Required :AC 208 volt
Input Voltage Range :AC 160 – 240 V
Frequency Required :40 – 70 hertz
Input Wiring :3-phase
Input Connector Type :Hardwire 5-wire (3PH + N + G)
Input Connector Qty :1
Output Connector Type :Hardwire 5-wire (3PH + N + G), Hardwire 4-wire (3PH + G), Terminal block (screw)
Output Connector Qty :3
Power Device Features :LCD display, Built-in static bypass, Built-in maintenance bypass, Audible alarm
Power Output Connectors Details
Power Output Connectors Details :1 x terminal block (screw), 1 x hardwire 4-wire (3PH + G), 1 x hardwire 5-wire (3PH + N + G)
Battery
Run Time (Up To) :19 minute (time unit)
Load Type :At full load
Recharge Time :5 Hours
Run Time Details
Run Time (Up To) :19 min at full load
