Output
Max Configurable Power (Watts)
108.0kWatts / 120.0kVA
Neutral Output Current
260A
Output Voltage Note
Configurable for 380 : 400 or 415 V 3 Phase nominal output voltage
Efficiency at Full Load
93.0 %
Output Voltage Distortion
Less than 2%
Output Frequency (sync to mains)
50 Hz – programmable +/- 0.5 / 1 / 2 / 4 / 6 / 8%
Output Frequency (not synced)
50Hz +/- 0.1% for 50Hz nominal
Other Output Voltages
380, 415
Load Crest Factor
3 : 1
Topology
Double Conversion Online
Waveform type
Sine wave
Overload Operation
10 minutes @ 125% and 60 seconds @ 150%
Maximum Output Current
480
Output Voltage THD
< 1% linear load and < 2.5% nonlinear load Output Voltage Tolerance +/- 2% static and 100% load step Bypass Built-in Maintenance Bypass, Built-in Static Bypass, Optional External Bypass Input Input frequency 45 – 65 Hz Input voltage range for main operations 323 – 437 (380V), 340 – 460 (400V), 353 – 477 (415V)V Efficiency at Full Load 93.0 % Input Total Harmonic Distortion Less than 3% for full load Type of Input Protection Required gL fuse Other Input Voltages 380, 415 Maximum Short Circuit Withstand (Icw) 30.0kAmps Input Power Factor at Full Load 1.0 Batteries & Runtime Battery type No internal battery – uses external battery system Expected Battery Life (years) 8 – 10 Battery Volt-Amp-Hour Capacity 93 Runtime View Runtime Graph View Runtime Chart Communications & Management Pre-Installed SmartSlot™ Cards AP9635CH Control panel Multi-function LCD status and control console Emergency Power Off (EPO) Yes Available SmartSlot™ Interface Quantity 3 Physical Maximum Height 87.01inches (2210MM, 221.0CM) Maximum Width 28.03inches (712MM, 71.2CM) Maximum Depth 33.66inches (855MM, 85.5CM) Net Weight 1293.6lbs. (588.0KG) Shipping weight 1342.0lbs. (610.0KG) Shipping Height 92.13inches (2340MM, 234.0CM) Shipping Width 42.52inches (1080MM, 108.0CM) Shipping Depth 47.24inches (1200MM, 120.0CM) Units per Pallet 1.0 Environmental Operating Temperature 32 – 104 °F (0 – 40 °C) Operating Relative Humidity 0 – 95 % Operating Elevation 0-3333ft (0-999.9meters) Storage Temperature -20 – 45 °C Storage Relative Humidity 0 – 95 % Storage Elevation 0-40000ft (0-12000meters) Audible noise at 1 meter from surface of unit 63.0dBA Protection Class IP 32, IP20 Conformance
