Output
Max Configurable Power (Watts)
37.5kWatts / 37.5kVA
Output Voltage Distortion
Less than 2%
Output Frequency (sync to mains)
60 Hz
Output Frequency (not synced)
60Hz +/- 0.1% for 60Hz nominal
Load Crest Factor
3 : 1
Waveform type
Sine wave
Overload Operation
150% for 1 minute 125% for 10 minutes
Output Voltage THD
< 2% for 0 to 100% linear load and < 5% for full non linear load Bypass Built-in Bypass Input Input frequency 60 Hz Input Total Harmonic Distortion Less than 5% for full load Maximum Short Circuit Withstand (Icw) 65.0kAmps Batteries & Runtime Battery type No internal battery – uses external battery system Communications & Management Pre-Installed SmartSlot™ Cards AP9635 Control panel Multi-function LCD status and control console Audible Alarm Audible and visible alarms prioritized by severity Available SmartSlot™ Interface Quantity 1 Physical Maximum Height 82.68inches (2100MM, 210.0CM) Maximum Width 23.62inches (600MM, 60.0CM) Maximum Depth 31.5inches (800MM, 80.0CM) Net Weight 1589.53lbs. (721.0KG) Shipping weight 1589.53lbs. (721.0KG) Shipping Height 82.68inches (2100MM, 210.0CM) Shipping Width 23.62inches (600MM, 60.0CM) Shipping Depth 31.5inches (800MM, 80.0CM) Color Light grey Environmental Operating Temperature 32 – 104 °F (0 – 40 °C) Operating Relative Humidity 0 – 95 (non-condensing) % Operating Elevation 0-3281ft (0-984.3meters) Storage Temperature -15 – 40 °C Storage Relative Humidity 0 – 95 (non-condensing) % Storage Elevation 0-16404ft (0-4921.2meters) Audible noise at 1 meter from surface of unit 65.0dBA Online thermal dissipation 14059.0BTU/hr Protection Class NEMA 1, IP 42 and air filter
