Output
Max Configurable Power (Watts)
144.0kWatts / 160.0kVA
Neutral Output Current
195A
Output Voltage Distortion
Less than 2%
Output Frequency (sync to mains)
50/60 Hz +/-1 Hz
Output Frequency (not synced)
50/60 Hz +/-1 Hz
Load Crest Factor
Unlimited
Topology
Double Conversion Online
Waveform type
Sine wave
Overload Operation
10 minutes @ 125% and 60 seconds @ 150%
Output Voltage THD
< 2% linear load and <3% non-linear load Output Voltage Tolerance +/- 1% static and +/- 3% at 100% load step Bypass Built-in Static Bypass Input Input frequency 40 – 70 Hz Input voltage range for main operations 360 – 576 (480)V Input voltage adjustable range for mains operation 360 – 576 (480)V Input Total Harmonic Distortion Less than 3% for full load Type of Input Protection Required 3-pole breaker Maximum Short Circuit Withstand (Icw) 65.0kAmps Input Power Factor at Full Load 1.0 Batteries & Runtime Battery type No internal battery – uses external battery system Nominal Battery Voltage 480V End of Discharge Maximum Battery Current 440.0A Expected Battery Life (years) 7 – 10 End of Discharge Battery Voltage 384 Efficiency in Battery Operation 95.5 % Maximum Available Short Circuit Current 65kAmps Overload Operation 60 seconds @ 125% and 30 seconds @ 150% Efficiency View Efficiency Graph Communications & Management Control panel 7″ Touch Screen Display Audible Alarm Audible and visible alarms prioritized by severity
