Output
Max Configurable Power (Watts)
10.0kWatts / 10.0kVA
Output Voltage Distortion
Less than 3%
Output Frequency (sync to mains)
50 Hz, 60 Hz
Output Frequency (not synced)
60Hz +/- 0.1% for 60Hz nominal, 50Hz +/- 0.1% for 50Hz nominal
Other Output Voltages
200, 220
Load Crest Factor
2.5
Topology
Double Conversion Online
Waveform type
Sine wave
Overload Operation
150% for 1 minute 125% for 10 minutes
Output Voltage THD
<1% linear load and <3% non-linear load Output Voltage Tolerance +/-1% after 50ms Bypass Built-in Static Bypass Input Input frequency 40 – 70 Hz Input voltage range for main operations 177 – 239 (208V)V Input Total Harmonic Distortion Less than 3% for full load Other Input Voltages 200, 220 Input Power Factor at Full Load 0.99 Batteries & Runtime Battery type No internal battery – uses external battery system Nominal Battery Voltage 384-480VDC End of Discharge Maximum Battery Current 34.0A End of Discharge Battery Voltage 307 VDC Efficiency View Efficiency Graph Communications & Management Interface Port(s) GVS_Cable2ndBatCab, GVS_MBCKIT_UL, GVS_NarrowCBC_Seismic, GVS_NarrowSeismicKit, GVS_Parallel, GVS_WideCBC_Seismic, GVS_WideUPS_AirFilter, GVS_WideUPSMBC_SeismicKit, GVS_XFMRSeismicKit Control panel Touch Screen LCD User Interface Audible Alarm Audible and visible alarms prioritized by severity Available SmartSlot™ Interface Quantity 1 Physical Maximum Height 58.46inches (1485MM, 148.5CM) Maximum Width 20.51inches (521MM, 52.1CM) Maximum Depth 33.35inches (847MM, 84.7CM) Net Weight 462.97lbs. (210.0KG) Shipping weight 518.09lbs. (235.0KG) Shipping Height 66.14inches (1680MM, 168.0CM) Shipping Width 25.2inches (640MM, 64.0CM)
