Output
Max Configurable Power (Watts)
15.0kWatts / 15.0kVA
Output Voltage Distortion
Less than 3%
Output Frequency (sync to mains)
50 Hz, 60 Hz
Output Frequency (not synced)
60Hz +/- 0.1% for 60Hz nominal, 50Hz +/- 0.1% for 50Hz nominal
Other Output Voltages
200, 220
Load Crest Factor
2.5
Topology
Double Conversion Online
Waveform type
Sine wave
Overload Operation
150% for 1 minute 125% for 10 minutes
Output Voltage THD
<1% linear load and <3% non-linear load Output Voltage Tolerance +/-1% after 50ms Bypass Built-in Static Bypass Input Input frequency 40 – 70 Hz Input voltage range for main operations 177 – 239 (208V)V Input Total Harmonic Distortion Less than 3% for full load Other Input Voltages 200, 220 Maximum Short Circuit Withstand (Icw) 65.0kAmps Input Power Factor at Full Load 0.99 Batteries & Runtime Battery type No internal battery – uses external battery system Nominal Battery Voltage 384-480VDC End of Discharge Maximum Battery Current 51.0A End of Discharge Battery Voltage 307 VDC Efficiency View Efficiency Graph Communications & Management Interface Port(s) GVS_Cable2ndBatCab, GVS_MBCKIT_UL, GVS_NarrowCBC_Seismic, GVS_NarrowSeismicKit, GVS_Parallel, GVS_WideCBC_Seismic, GVS_WideUPS_AirFilter, GVS_WideUPSMBC_SeismicKit, GVS_XFMRSeismicKit Control panel Touch Screen LCD User Interface Audible Alarm Audible and visible alarms prioritized by severity Available SmartSlot™ Interface Quantity 1 Physical Maximum Height 58.46inches (1485MM, 148.5CM) Maximum Width 20.51inches (521MM, 52.1CM) Maximum Depth 33.35inches (847MM, 84.7CM) Net Weight 462.97lbs. (210.0KG) Shipping weight 518.09lbs. (235.0KG)
