Output
Max Configurable Power (Watts)
20.0kWatts / 20.0kVA
Output Voltage Distortion
Less than 3%
Output Frequency (sync to mains)
50 Hz, 60 Hz
Output Frequency (not synced)
60Hz +/- 0.1% for 60Hz nominal, 50Hz +/- 0.1% for 50Hz nominal
Load Crest Factor
2.5
Topology
Double Conversion Online
Waveform type
Sine wave
Overload Operation
150% for 1 minute 125% for 10 minutes
Output Voltage THD
<1% linear load and <3% non-linear load Output Voltage Tolerance +/-1% after 50ms Bypass Built-in Static Bypass Input Input frequency 40 – 70 Hz Input voltage range for main operations 408 – 552 (480)V Input Total Harmonic Distortion Less than 3% for full load Maximum Short Circuit Withstand (Icw) 65.0kAmps Input Power Factor at Full Load 0.99 Batteries & Runtime Battery type VRLA Nominal Battery Voltage 480V End of Discharge Maximum Battery Current 54.0A End of Discharge Battery Voltage 384 Vdc Efficiency View Efficiency Graph Communications & Management Interface Port(s) GVS_350mm_AirFilter, GVS_350mm_Seismic, GVSAIO_BypassCabinetCables_UL, GVSAIO_MBP_UL Control panel Touch Screen LCD User Interface Audible Alarm Audible and visible alarms prioritized by severity Available SmartSlot™ Interface Quantity 1 Physical Maximum Height 58.46inches (1485MM, 148.5CM) Maximum Width 13.11inches (333MM, 33.3CM) Maximum Depth 33.35inches (847MM, 84.7CM) Net Weight 540.13lbs. (245.0KG) Shipping weight 595.25lbs. (270.0KG) Shipping Height 66.14inches (1680MM, 168.0CM) Shipping Width 25.2inches (640MM, 64.0CM) Shipping Depth 38.98inches (990MM, 99.0CM) Color Gloss level 85%, RAL 9003, White
