Output
Max Configurable Power (Watts)
25.0kWatts / 25.0kVA
Output Voltage Distortion
Less than 5%
Output Frequency (sync to mains)
50Hz, 60Hz
Output Frequency (not synced)
50Hz +/-0.1% for 50Hz nominal, 60Hz +/-0.1% for 60Hz nominal
Other Output Voltages
200, 220
Load Crest Factor
2.5
Topology
Double Conversion Online
Waveform type
Sinewave
Overload Operation
150% for 1 minute 125% for 10 minutes
Output Voltage THD
<2% linear load and <5% non-linear load Output Voltage Tolerance +/-1% after 50ms Bypass Built in static bypass Input Input frequency 40-70Hz Input voltage range for main operations 177-239V Input Total Harmonic Distortion Less than 3% at full load Other Input Voltages 200, 220 Maximum Short Circuit Withstand (Icw) 65.0kAmps Input Power Factor at Full Load 0.99 Batteries & Runtime Battery type VRLA Nominal Battery Voltage 480 End of Discharge Maximum Battery Current 68.0A End of Discharge Battery Voltage 384VDC Efficiency View Efficiency Graph Communications & Management Control panel Touchscreen LCD user interface Audible Alarm Audible and visible alarms prioritized by severity Physical Maximum Height 58.0inches (1485MM, 148.5CM) Maximum Width 20.0inches (521MM, 52.1CM) Maximum Depth 34.0inches (847MM, 84.7CM) Net Weight 440.92lbs. (200.0KG) Shipping weight 440.0lbs. (200.0KG) Shipping Height 66.0inches (1680MM, 168.0CM) Shipping Width 26.0inches (640MM, 64.0CM) Shipping Depth 38.0inches (990MM, 99.0CM) Color Gloss level 85%, RAL 9003, White Environmental Operating Temperature 32 – 104 °F (0 – 40 °C) Operating Relative Humidity 0 to 95% non-condensing % Operating Elevation 0-3300ftft (0-990meters) Storage Temperature -15 – 40 °C Storage Relative Humidity 10 to 80% non-condensing % Storage Elevation 0-10|000ftft (0-3meters) Audible noise at 1 meter from surface of unit 61.0dBA Online thermal dissipation 5950.0BTU/hr Protection Class IP20 Conformance Approvals CSA C22.2 NO. 107.3, FCC Part 15 Class A, IEC 62040-1-1, IEC 62040-2, IEC 62040-3, UL 1778 5th edition, OSHPD Standard warranty 1 year on-site repair or replace with factory authorized Start-Up
