Output
Max Configurable Power (Watts)
50.0kWatts / 50.0kVA
Output Voltage Distortion
Less than 3%
Output Frequency (sync to mains)
50Hz, 60Hz
Output Frequency (not synced)
50Hz +/-0.1% for 50Hz nominal, 60Hz +/-0.1% for 60Hz nominal
Load Crest Factor
2.5
Topology
Double Conversion Online
Waveform type
Sinewave
Overload Operation
150% for 1 minute 125% for 10 minutes
Output Voltage THD
<1% linear load and <3% non-linear load Output Voltage Tolerance +/-1% after 50ms Bypass Built in static bypass Input Input frequency 40-70Hz Input voltage range for main operations 408 – 552 (480)V Input Total Harmonic Distortion Less than 6% at full load Maximum Short Circuit Withstand (Icw) 65.0kAmps Input Power Factor at Full Load 0.99 Batteries & Runtime Battery type VRLA Nominal Battery Voltage 480VDC End of Discharge Maximum Battery Current 136.0A End of Discharge Battery Voltage 384VDC Efficiency View Efficiency Graph Communications & Management Control panel Touchscreen LCD user interface Audible Alarm Audible and visible alarms prioritized by severity Physical Maximum Height 78.0inches (1970MM, 197.0CM) Maximum Width 22.0inches (550MM, 55.0CM) Maximum Depth 34.0inches (847MM, 84.7CM) Net Weight 551.16lbs. (250.0KG) Shipping weight 552.0lbs. (250.0KG) Shipping Height 82.0inches (2082MM, 208.2CM) Shipping Width 30.0inches (755MM, 75.5CM) Shipping Depth 40.0inches (1010MM, 101.0CM) Color Gloss level 85%, RAL 9003, White
