Output
Max Configurable Power (Watts)
1.25MWatts / 1.25MVA
Output Frequency (sync to mains)
50 Hz, 60 Hz
Output Frequency (not synced)
50Hz +/- 0.1% for 50Hz nominal
Other Output Voltages
380, 415, 440
Load Crest Factor
3 with THC <5% Topology Double Conversion Online Waveform type Sine wave Overload Operation 150% for 1 minute 125% for 10 minutes Output Voltage THD < 2% linear load and <3% non-linear load Input Input frequency 40 – 70 Hz Input Total Harmonic Distortion Less than 3% for full load Other Input Voltages 380, 415, 440 Maximum Short Circuit Withstand (Icw) 100.0kAmps Input Power Factor at Full Load 1.0 Batteries & Runtime Battery type No internal battery – uses external battery system Nominal Battery Voltage 480V End of Discharge Battery Voltage 384 Vdc Efficiency View Efficiency Graph Communications & Management Control panel 7″ Touch Screen Display Audible Alarm Audible and visible alarms prioritized by severity Available SmartSlot™ Interface Quantity 2 Physical Maximum Height 77.56inches (1970MM, 197.0CM) Maximum Width 196.85inches (5000MM, 500.0CM) Maximum Depth 35.43inches (900MM, 90.0CM) Net Weight 7605.95lbs. (3450.0KG) Shipping weight 9773.1lbs. (4433.0KG) Shipping Height 84.65inches (2150MM, 215.0CM) Shipping Width 232.28inches (5900MM, 590.0CM) Shipping Depth 41.73inches (1060MM, 106.0CM) Color White Environmental Operating Temperature 32 – 104 °F (0 – 40 °C) Operating Relative Humidity 0 – 95 (non-condensing) % Operating Elevation 0-3333ft (0-999.9meters) Storage Temperature -15 – 40 °C Storage Relative Humidity 0 – 95 (non-condensing) % Storage Elevation 0-50000ft (0-15000meters) Audible noise at 1 meter from surface of unit 68.0dBA Online thermal dissipation 217914.0BTU/hr Protection Class IP 20 Conformance Approvals C-tick, CE, EN/IEC 62040-1, EN/IEC 62040-2, EN/IEC 62040-3, IBC 2012, IEC 62040-4, ISTA 2B
