Output
Max Configurable Power (Watts)
500.0kWatts / 500.0kVA
Output Frequency (sync to mains)
50 Hz, 60 Hz
Output Frequency (not synced)
50Hz +/- 0.1% for 50Hz nominal
Other Output Voltages
380, 415, 440
Load Crest Factor
3 with THC <5% Topology Double Conversion Online Waveform type Sine wave Overload Operation 150% for 1 minute 125% for 10 minutes Output Voltage THD < 2% linear load and <3% non-linear load Input Input frequency 40 – 70 Hz Input Total Harmonic Distortion Less than 3% for full load Other Input Voltages 380, 415, 440 Maximum Short Circuit Withstand (Icw) 100.0kAmps Batteries & Runtime Battery type No internal battery – uses external battery system Nominal Battery Voltage 480V End of Discharge Battery Voltage 384 Vdc Efficiency View Efficiency Graph Communications & Management Control panel 7″ Touch Screen Display Audible Alarm Audible and visible alarms prioritized by severity Available SmartSlot™ Interface Quantity 2 Physical Maximum Height 77.56inches (1970MM, 197.0CM) Maximum Width 106.3inches (2700MM, 270.0CM) Maximum Depth 35.43inches (900MM, 90.0CM) Net Weight 4144.69lbs. (1880.0KG) Shipping weight 5714.39lbs. (2592.0KG) Shipping Height 84.65inches (2150MM, 215.0CM) Shipping Width 124.8inches (3170MM, 317.0CM) Shipping Depth 41.73inches (1060MM, 106.0CM) Color White Environmental Operating Temperature 32 – 104 °F (0 – 40 °C) Operating Relative Humidity 0 – 95 (non-condensing) % Operating Elevation 0-3333ft (0-999.9meters) Storage Temperature -15 – 40 °C Storage Relative Humidity 0 – 95 (non-condensing) % Storage Elevation 0-50000ft (0-15000meters) Audible noise at 1 meter from surface of unit 69.5dBA Online thermal dissipation 82435.0BTU/hr
