Output
Max Configurable Power (Watts)
750.0kWatts / 750.0kVA
Output Frequency (sync to mains)
60 Hz
Output Frequency (not synced)
60Hz +/- 0.1% for 60Hz nominal
Load Crest Factor
3 : 1
Topology
Double Conversion Online
Waveform type
Sine wave
Overload Operation
10 minutes @ 125% and 60 seconds @ 150%
Output Voltage THD
< 2% linear load and <3% non-linear load Output Voltage Tolerance +/- 1% symmetrical load and +/- 3% asymmetrical lo Bypass Built-in Static Bypass, Optional External Bypass Input Input frequency 40 – 70 Hz Input voltage range for main operations 408 – 600VV Input Total Harmonic Distortion Less than 3% for full load Maximum Short Circuit Withstand (Icw) 100.0kAmps Input Power Factor at Full Load 0.99 Batteries & Runtime Battery type No internal battery – uses external battery system End of Discharge Battery Voltage 384 Vdc Efficiency View Efficiency Graph Communications & Management Interface Port(s) GVX_750G_1Feed Control panel Touch Screen LCD User Interface Audible Alarm Audible and visible alarms : configurable delays Emergency Power Off (EPO) Optional Available SmartSlot™ Interface Quantity 1 Physical Maximum Height 77.56inches (1970MM, 197.0CM) Maximum Width 106.3inches (2700MM, 270.0CM) Maximum Depth 35.43inches (900MM, 90.0CM) Net Weight 4695.0lbs. (2129.61KG) Shipping weight 5714.0lbs. (2591.82KG) Shipping Height 84.65inches (2150MM, 215.0CM) Shipping Width 124.8inches (3170MM, 317.0CM)
