Output
Max Configurable Power (Watts)
625.0kWatts / 625.0kVA
Output Frequency (sync to mains)
50 Hz, 60 Hz
Output Frequency (not synced)
50Hz +/- 0.1% for 50Hz nominal
Other Output Voltages
380, 415, 440
Load Crest Factor
3 with THC <5% Topology Double Conversion Online Waveform type Sine wave Overload Operation 150% for 1 minute 125% for 10 minutes Output Voltage THD < 2% linear load and <3% non-linear load Input Input frequency 40 – 70 Hz Input Total Harmonic Distortion Less than 3% for full load Other Input Voltages 380, 415, 440 Maximum Short Circuit Withstand (Icw) 100.0kAmps Batteries & Runtime Battery type No internal battery – uses external battery system Nominal Battery Voltage 480V End of Discharge Battery Voltage 384 Vdc Efficiency View Efficiency Graph Communications & Management Control panel 7″ Touch Screen Display Audible Alarm Audible and visible alarms prioritized by severity Available SmartSlot™ Interface Quantity 2 Physical Maximum Height 77.56inches (1970MM, 197.0CM) Maximum Width 129.92inches (3300MM, 330.0CM) Maximum Depth 35.43inches (900MM, 90.0CM) Net Weight 5335.19lbs. (2420.0KG) Shipping weight 7248.81lbs. (3288.0KG) Shipping Height 84.65inches (2150MM, 215.0CM) Shipping Width 153.94inches (3910MM, 391.0CM) Shipping Depth 41.73inches (1060MM, 106.0CM) Color White Environmental Operating Temperature 32 – 104 °F (0 – 40 °C) Operating Relative Humidity 0 – 95 (non-condensing) % Operating Elevation 0-3333ft (0-999.9meters) Storage Temperature -15 – 40 °C Storage Relative Humidity 0 – 95 (non-condensing) % Storage Elevation 0-50000ft (0-15000meters) Audible noise at 1 meter from surface of unit 69.5dBA Online thermal dissipation 112040.0BTU/hr Protection Class IP 20 Conformance Approvals cUL Listed, C-tick, CE, IBC 2012, IEC 62040-1-1, IEC 62040-2, IEC 62040-3, IEC 62040-4, ISTA 2B, UL 1778 5th edition Standard warranty 1 year on-site repair or replace with factory authorized Start-Up Sustainable Offer Status RoHS Compliant REACH REACH: Contains No SVHCs Battery Directive Compliant Proposition 65 Warning Available in Documentation tab Documentation Manuals and Warranties Galaxy VX UPS with 1000 kW IO Cabinet 400/480 V Installation Providing the certified electrician with information on how to install and connect the Galaxy VX UPS.
