Manufacturer :Netscreen
Brand :Juniper, Juniper Networks
Product Line :Juniper Networks JSA Series
Model :JSA5500
Packaged Quantity :1
Processor
Installed Qty :2
RAM
Installed Size :96 GB
Storage Controller
RAID Level :RAID 10
Hard Drive
Type :HDD
Hot-Swap :Hot-swap
Interface Type :Serial ATA-300 / SAS
Installed Qty :8
Capacity :1 TB
Performance
Performance :Event traffic: 1000 events per second, Flow capacity: 600000 flows per second
Networking
Type :Security appliance
Form Factor :Rack-mountable
Ports Qty :4
Connectivity Technology :Wired
Data Link Protocol :Fast Ethernet, Gigabit Ethernet, Ethernet
Data Transfer Rate :1 GBps
Features :Flow control, Redundant hot swappable fans, J-Flow, sFlow, IPFIX, Store and forward
Expansion Slots
Expansion Slots :2 (total) / 2 (free) x expansion slot
Interface Provided
Interfaces :1 x management – RJ-45, 4 x 1000Base-T – RJ-45
Power Device
Type :Internal power supply
Hot-Plug :Hot-plug
Power Redundancy :Yes
Installed Qty :2
Max Supported Qty :2
Power Provided :560 watt
Nominal Voltage :AC 120/230 V
Frequency Required :50/60 hertz
80 PLUS Certification :80 PLUS
Miscellaneous
Height (Rack Units) :2
Encryption Algorithm :SHA
Compliant Standards :IEC 60950-1, EN 60825-1, FCC Class A certified, PCI DSS, HIPAA, VCCI Class A, SOX, EN 61000-3-2, EN 60950-1, UL 60950-1, EN55022 Class A, EN55024, CSA C22.2 No. 60950-1, EN 60825-2
Dimensions & Weight
Width :23.5 inch
Depth :17.3 inch
Height :3.5 inch
Weight :41.23 lbs
Environmental Parameters
Min Operating Temperature :41 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Humidity Range Operating :8 – 90% (non-condensing)
