Manufacturer :Netscreen
Brand :Juniper, Juniper Networks
Product Line :Juniper Networks NetScreen
Model :ISG 1000 Baseline
Packaged Quantity :1
Optical Storage
Type :None
Card Reader
Supported Flash Memory Cards :CompactFlash Card
Performance
Performance :Firewall throughput: 1 Gbps, 3DES throughput: 1 Gbps
Capacity
Capacity :Connection / user qty: unlimited, Authenticated users (internal database): 5000, Concurrent VPN tunnels: 1000, Static routes: 10000, Security policies: 10000, Concurrent sessions: 125000
Networking
Type :Security appliance
Form Factor :Rack-mountable
Connectivity Technology :Wired
Data Link Protocol :Ethernet, Fast Ethernet, Gigabit Ethernet
Routing Protocol :RIP-1, Static IP routing, RIP-2
Network / Transport Protocol :PPPoE, IPSec, L2TP
Remote Management Protocol :HTTPS, SNMP 2, SNMP, HTTP
Features :Transparency, URL filtering, High Availability, VPN support, Routing, 56-bit encryption, Modular design, 168-bit encryption, DiffServ support, Firewall protection, VLAN support, DHCP support, DoS attack prevention, Syslog support, NAT support, LDAP support, PAT support
Compliant Standards :X.509
IP Telephony
VoIP :Yes
VoIP Protocols :SIP, MGCP, SCCP, H.323
Expansion Slots
Expansion Slots :2 (total) / 2 (free) x expansion slot
Interface Provided
Interfaces :1 x management – RJ-45, 4 x 1000Base-T – RJ-45
OS Provided
Type :ScreenOS
Power Device
Type :Internal power supply
Power Provided :250 watt
Nominal Voltage :AC 120/230 V
Miscellaneous
Encryption Algorithm :RSA, MD5, IKE, Triple DES, SHA-1, PKI, AES, DES
Authentication Method :Secure Shell v.2 (SSH2), X.509 certificates, LDAP, RADIUS
Compliant Standards :C-Tick, FCC Class B certified, BSMI, CB, VCCI Class A ITE, cUL, UL, CSA
Dimensions & Weight
Width :17.5 inch
Depth :17.2 inch
Height :5.2 inch
Weight :29.98 lbs
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :122 degree Fahrenheit
Humidity Range Operating :10 – 90%
