CPU
Chipset AMD X570
CPU Socket AM4
Back Panel I/O
USB 2 x USB 3.1 / USB 3.2 Gen 1 Type-A
4 x USB 3.1 / USB 3.2 Gen 2 Type-A
1 x USB 3.1 / USB 3.2 Gen 2 Type-C
Thunderbolt None
Display 1 x DisplayPort
1 x HDMI
Audio 5 x 3.5 mm
1 x S/PDIF
Ethernet / Controller 1 x Realtek RTL8117 Gigabit
1 x Intel I211-AT Gigabit
Memory
Memory Slots 4 x 288-Pin
Memory Support DDR4 MHz
Maximum Capacity 128 GB
Channel Architecture Dual Channel
ECC Support Non-ECC, ECC Unbuffered
Storage Expansion
SATA 4 x SATA III
M.2 1 x M Key 2242, 2260, 2280, 22110 (PCIe 4.0 x4, SATA III)
1 x M Key 2242, 2260, 2280 (PCIe 4.0 x4)
