Input Operating Range: 90-264VAC ; 47-63Hz
Input In-rush Current: 35A Max
Input Current: 2.2A @ 115VAC ; 1.10A @ 230VAC
Output Voltage: 47~ 56VDC (adjustable)
Cont. Load Current: 2.5A
Maximum Output Power: 120W
Peak Power (10sec @ 220VAC): 180W
Line Regulation: +/- 0.5%
Load Regulation: +/- 1%
Voltage Overshoot: <5% Ripple / Noise: 100mV Peak Efficiency: 90% Minimum Dielectric Strength: 1500V rms , 1 min, 10mA Max Insulation Resistance: 10M Ohms Protection: Short Circuit, Over-Voltage, Over-Current, Over Power
