Dimensions (W x H x D)
QFX5110-32Q: 17.36 x 1.72 x 20.48 in (44.09 x 4.37 x 52.02 cm); 1 U
Power options
100 to 240 VAC (single phase) at 50/60 Hz or –36 to –72 VDC
System Throughput
QFX5110-32Q: 2.56 Tbps
Form Factor
Fixed-configuration platform
Data Rate (switching capacity)
QFX5110-32Q: 1.44 Bpps
Port densities
QFX5110-32Q: 104 10GbE (with breakout cable); 32 40GbE; 20 40GbE with 4 100GbE
Maximum 10GbE Density
QFX5110-32Q: 104 ports with breakout cable
Maximum 25GbE / 50GbE Densities
N / A
Maximum 40GbE Density
QFX5110-32Q: 32 ports
Maximum 100GbE Density
QFX5110-48S / -32Q: 4
Resiliency
Dual hot-swappable AC or DC power supplies for 1 + 1 redundancy.
Hot-swappable fan trays.
Power Consumption
