Media Type: Single-Mode Fiber (SMF)
Connectors: Double LC
TX Wavelength: 1270 nm, 1290 nm, 1310 nm, 1330 nm
RX Wavelength: 1290 nm, 1270 nm, 1310 nm., 1330 nm.
Minimum Optical Budget: 7 dB
Maximum Distance: 10km
Supported Data Rate: 103.125-112.2 Gbps
Supported Applications: 100G Ethernet (103.125Gbps), 4x 32G Fiber Channel (112.2Gbps), OTU4 4l1-9D1F (112 Gbps)
DDM/DOM: Supported
CDR (Clock and Data Recovery) chip: Supported
Forward Error Correction (FEC): Host FEC Supported
Transmitter Type: DML LAN WDM TOSA
Minimum Transmitting Power: Each Lane -6.5 dB
Tx Wavelength Bandwidth: 4 CWDM Lanes (73 nm 1264.50 – 1337.50nm) (L0 Tx center 1271nm, L1 Tx center 1291nm, L2 Tx center 1311nm, L3 Tx center 1331nm)
Maximum Transmitting Power: Each Lane 2.5 dB
