General information :
Manufacturer: hewlett-packard
Manufacturer part number: 257918-001
Product name: proliant ml370 Gen3 5u rack server
Processor & chipset :
Processor type: intel xeon 2.4ghz
Installed qty: 1
Max supported qty: 2
Upgradability: upgradable
Chipset type: serverworks grand champion le
Data bus speed: 400 mhz
Cache memory :
Cache memory type: l2 cache-advanced transfer cache
Installed size: 512 kb
Cache per processor: 512 kb
Memory :
Installed size: 512 mb
Max supported size : 12 gb
Technology: ddr sdram-ecc
Memory speed: 266 mh
Memory specification compliance: pc210
Form factor: dimm 184-pin
Storage :
Floppy drive: 3.5in 1.44 mb floppy
Hard drive: none
Optical storage type: cd-rom – ide
Read speed: 48x
Storage controller :
Storage controller type(1st): 1 x scsi-integrated
Controller interface type: ultra160 scsi
Channel qty: 2
Storage controller type(2nd): 1 x ide-integrated
Controller interface type: eide/atapi
Display & graphics controller :
Graphics controller type: pci-integrated
Graphics processor: ati rage xl
Video memory: sdram
Installed size: 8 mb/8 mb (max)
Networking :
Networking: network adapter-pci-x-integrated
Data link protocol: ethernet,fast ethernet,gigabit ethernet
Features: full duplex capability, wake on lan (wol)
Compliant standards: ieee 802.3, ieee 802.3u
Expansions & connectivity :
Expansion bays total (free):
1 ( 0 ) x front accessible-3.5in x 1/3h
3 ( 2 ) x front accessible-5.25in x 1/2
6 ( 6 ) x hot-swap-3.5in x 1/3h
Expansion slots total (free):
2 ( 1 ) x processor-socket 603
6 ( 4 ) x memory-dimm 184-pin
6 ( 6 ) x pci-x/100 mhz
Interfaces & ports :
1 x parallel-ieee 1284 (epp/ecp)-25 pin d-sub (db-25)
2 x serial-rs-232-9 pin d-sub (db-9)
1 x mouse-generic-6 pin mini-din (ps/2 style)
1 x keyboard-generic-6 pin mini-din (ps/2 style)
1 x display/video-vga-15 pin hd d-sub (hd-15)
2 x usb-4 pin usb type a
1 x network-ethernet 10base-t/100base-tx-rj-45
1 x management
1 x storage-ultra160 scsi-68 pin vhdci (mini-centronics)
Power device :
Power device type: power supply-hot-plug
Power redundancy: optional
Power redundancy scheme: 1+1 (with optional power supply)
Installed qty: 1
Max supported qty: 2
Voltage required: ac 110/220 v ± 18% ( 50/60 hz )
Power provided: 500 watt
