GENERAL
Packaged Quantity1
Product Line : ProLiant
Product Series : ML370
Recommended Usecorporate business
Product Form Factor 5U Rack mount
Built-in DevicesLED panel
Server Scalability2-way
Front Accessible Bays Qty4
Hot Swap Qty6 6 Bays
Manufacturer Compaq
PROCESSOR / CHIPSET
CPU Intel Xeon 2.8 GHz
Data Bus Speed400 MHz
Chipset TypeServerWorks Grand Champion LE
Processor SocketSocket 603
CACHE MEMORY
Installed SizeL2 cache – 512 KB Advanced Transfer Cache
Cache Per Processor512 KB
MEMORY
Max Supported Size12 GB
Form FactorDIMM 184-pin
6 DDR Slots
Empty Slots4
RAM
Technology DDR SDRAM – ECC
Memory Speed200 MHz
Memory Specification CompliancePC2100
Featuresregistered
Upgrade Rule2 modules at a time
STORAGE
Typenone
Read Speed48x
ENVIRONMENTAL PARAMETERS
Humidity Range Operating5 – 95%
Sound Emission41 dBA
HARD DRIVE
TypeNo HDD
STORAGE CONTROLLER
Type1 x SCSI – integrated – PCI 64
Interface Type Ultra160 SCSI
Channel Qty2
STORAGE CONTROLLER (2ND)
Type1 x IDE – integrated – PCI
PROCESSOR
Installed Qty1
Max Supported Qty2
Upgradabilityupgradable
FLOPPY DRIVE
Type3.5″ 1.44 MB floppy
MISCELLANEOUS
Featuresadministrator password, disk configuration lock, diskette I/O control, parallel port I/O control, power-on password, serial port I/O control
Compliant StandardsACPI 1.0b
NETWORKING
Data Link ProtocolEthernet, Fast Ethernet, Gigabit Ethernet
Form Factorintegrated
Compliant StandardsIEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Interface (Bus) TypePCI-X
FeaturesFull duplex capability, wake on LAN (WOL)
MONITOR
Monitor TypeNone.
GRAPHICS CONTROLLER
Form Factorintegrated
Interface TypePCI
Graphics ProcessorATI RAGE XL
Video Memory8 MB / 8 MB (max) SDRAM
Video InterfacesVGA
DIMENSIONS & WEIGHT
Width19 in
Depth25.7 in
Height8.7 in
PRINTER
Typenone
PHYSICAL CHARACTERISTICS
Form Factorrack-mountable
Weight65.04 lbs
CLUSTER
Cluster Hard Drivenone
POWER
Typepower supply – hot-plug
Power Redundancyoptional
Power Redundancy Scheme1+1 (with optional power supply)
Installed Qty1
Max Supported Qty2
Min Operating Temperature41 °F
Nominal VoltageAC 120/230 V ( 50/60 Hz )
Max Operating Temperature95 °F
OPERATING SYSTEM / SOFTWARE
OS CertifiedCaldera OpenUnix 8, IBM OS/2 Warp Server for e-business, SCO OpenServer 5.0.6A, SuSE Linux Enterprise Server 7, Microsoft Windows 2000 Advanced Server, Microsoft Windows 2000 Server, Microsoft Windows NT Server 4.0, Microsoft Windows NT Server 4.0 Enterprise Edition, Novell NetWare 5.1, Novell NetWare 6, Red Hat Linux 7.3, Red Hat Linux Advanced Server
TypeCompaq ActiveUpdate, Compaq Insight Manager 7, Compaq Management Agents, Compaq ROMPaq, Compaq SmartStart, Compaq Survey Utility, Drivers & Utilitie
