GENERAL INFORMATION:
Manufacturer: Hewlett-Packard
Manufacturer Part Number: 311056-001
Product Name: Proliant Ml570r02 Server
PROCESSOR & CHIPSET:
Total Processors Support: 4
Processor: 2 X Intel Xeon Mp 2GHz
Cache: 2 X 2mb L3
Chipset: Serverworks Grand Champion-He
MEMORY:
Installed Memory: 1gb
Maximum Memory: 32gb
Technology: Ddr Sdram
Memory Speed: 200 Mhz
Memory Specification Compliance: Pc1600
Signal Processing: Registered
Error Checking: Advanced Ecc
Form Factor: Dimm 184-Pin
Memory Slots: 184-Pin Dimm (8 DDR Slots)
STORAGE:
Hard Drive: Not Included
Maximum Internal Storage Support: 4.2tb Hot Swap Scsi – (12 X 300gb Using Standard Drive Cages + 2 X 300gb Using Optional Drive Cage)
Optical Drive: Cd-Reader – Cd-Rom (Atapi)
STORAGE CONTROLLER
Storage Controller Type: 1 X Scsi – Integrated – Pci 64
Controller Interface Type: Ultra160 Scsi
Channel Qty: 2
STORAGE CONTROLLER (2ND)
Storage Controller Type: 1 X Ide – Integrated – Pci
Controller Interface Type: Eide
DISPLAY & GRAPHICS:
Graphics Controller Type: Pci – Integrated
Graphics Processor: Ati Rage Iic
Video Memory: 8 Mb / 8 Mb (Max) Sdram
NETWORK & COMMUNICATION:
Compaq Nc3163 10/100mbps Ieee 802.3u Fast Ethernet Pci Integrated
Networking: Network Adapter – Pci – Integrated
Data Link Protocol: Ethernet, Fast Ethernet
Features: Full Duplex Capability, Auto-Sensing Per Device, Wake On Lan (Wol)
I/O EXPANSIONS:
Expansion Bays:
2 X 5.25 1/2h External Removable Media Bay Free
1 X 5.25 1/2h External Removable Media Bay Populated
1 X External Removable Media Bay Total
12 X 1/3h Drive Bay Total Hot-Swappable
