GENERAL INFORMATION :
Manufacturer: Hewlett-Packard
Manufacturer Part Number: 359383-001
Product Name: Proliant Dl360 G3 1u Rack mount Server
PROCESSOR & CHIPSET :
Processor Type : Intel Xeon 2.8 GHz
Installed Qty : 1
Max Supported Qty : 2
Chipset Type : Serverworks Grand Champion Le
Data Bus Speed : 533 Mhz
MEMORY :
Installed Size : 1 Gb
Maximum Size : 8 Gb
Technology : Ddr Sdram – Ecc
Memory Speed : 266 Mhz
Memory Specification Compliance : Pc2100
Form Factor : Dimm 184-Pin
Features : Registered
Configuration Features : 2 X 512 Mb
Upgrade Rule : 2 Modules At A Time
CACHE MEMORY :
Cache Memory Type : L3 Cache
Installed Size : 1 Mb
Cache Per Processor : 1 Mb
STORAGE :
Hard Drive: Not Included
Hard Drive Interface: Ultra160 Scsi Hot Plug
Hard Drive Bays: 2 Front Accessible Hot Swap (2 Bays)
Optical Drive: 24x Cd-Rom Slimline
Removable Storage Drives: 1.44mb Floppy Drive
STORAGE CONTROLLERS :
Storage Controller (1st) Type : 1 X Raid – Integrated – Pci-X / 100 Mhz
Controller Interface Type : Ultra160 Scsi
Storage Controller Name : Smart Array 5i Plus Controller
Channel Qty : 2
Raid Level : Raid 0, Raid 1, Raid 5, Raid 10
Buffer Size : 64 Mb
Storage Controller (2nd) Type : 1 X Ide – Integrated
Controller Interface Type : Ide/Ata
Display & Graphics Controller :
Graphics Controller Type : Pci – Integrated
Graphics Processor : Ati Rage Xl
Video Memory : 8 Mb / 8 Mb (Max) Sdram
NETWORKING :
Networking: Two Nc7781 Pci-X Gigabit Nics
Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
Features: Wake On Lan (Wol)
Remote Management: 1 X Hp Ilo Remote Management
EXPANSIONS & CONNECTIVITY :
Expansion Bays Total (Free):
2 ( 2 ) X Hot-Swap – 3.5in X 1/3h,
1 ( 0 ) X Front Accessible – 3.5in Slim Line,
1 ( 0 ) X Front Accessible – 5.25in Slim Line
Expansion Slots Total (Free):
2 ( 1 ) X Processor – Socket 604,
4 ( 2 ) X Memory – Dimm 184-Pin,
2 ( 2 ) X Pci-X / 100 Mhz – Full-Length
INTERFACES & PORTS :
1 X Serial – Rs-232 – 9 Pin D-Sub (Db-9
1 X Keyboard – 6 Pin Mini-Din (Ps/2 Style
1 X Mouse – Generic – 6 Pin Mini-Din (Ps/2 Style
2 X Usb – 4 Pin Usb Type A
