GENERAL INFORMATION :
Manufacturer: Hewlett Packard
Manufacturer Part Number: 407658-001
Product Name: Proliant Dl585 G1 – 4u Rack Mount Server (Dual-Core Model)
PROCESSOR & CHIPSET :
Processor Type: Amd Dual-Core Opteron 885 / 2.6 Ghz
Multi-Core Technology: Dual-Core
64-Bit Computing: Yes
Installed Processor Qty: 2
Max Supported Qty: 4
Upgradability: Upgradable
CACHE MEMORY:
Type: L2 Cache
Installed Size: 2 Mb
Cache Per Processor: 2 Mb ( 2 X 1 Mb )
MEMORY:
Installed Ram Size: 2 Gb / 32 Gb (Max)
Memory Type: Ddr Sdram – Advanced Ecc
Memory Slots: 184-Pin Dimm
Features: Registered
STORAGE:
Hard Drive: Not Included
Optical Drive: 24x Cd-Rom – Ide
STORAGE CONTROLLERS:
Storage Controllers Type: 1 X Raid – Integrated – Pci-X / 100 Mhz
Controller Interface Type: Ultra160 Scsi
Storage Controller Name: Smart Array 5i Plus Controller
Channel Qty: 2
Raid Level: Raid 0, Raid 1, Raid 5, Raid 10
Buffer Size: 64 Mb
DISPLAY & GRAPHICS:
Type: Pci – Integrated
Video Memory: 8 Mb Sdram
NETWORK & COMMUNICATION:
Networking: Network Adapter – Pci-X / 133 Mhz – Integrated
Nic: Nc7782 Gigabit Ethernet 10/100/1000mbps Pci-X/133mhz Embedded
Ethernet Controller(S): Hp Nc7782
Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management: 1 X Ilo Remote Management
Features: Wake On Lan (Wol)
Compliant Standards: Ieee 802.3, Ieee 802.3u, Ieee 802.3ab
POWER DESCRIPTION:
Device Type: Power Supply – Hot-Plug
Power Redundancy: Yes
Power Redundancy Scheme: 1+1
Installed Qty: 2
Max Supported Qty: 2
Voltage Required: Ac 120/230 V ( 50/60 Hz )
Power Provided: 870 Watt
