General Information:
Manufacturer: Hewlett-Packard
Manufacturer Part Number: 443529-B21
Product Name: Proliant Bl680c G5 Server
Blade Server
Processor & Chipset:
Processor Type: Intel Xeon E7320 / 2.13 Ghz
Multi-Core Technology: Quad-Core
64-Bit Computing: Yes
Installed Processor Qty: 2
Max Supported Qty: 2
Chipset: Intel 7300
Cache Memory:
Cache Memory Type: L2 Cache
Installed Size: 8 Mb
Cache Per Processor: 4 Mb
Memory:
Installed Ram Memory: 8 Gb
Maximum Memory: 64gb
Technology: Ddr2 Sdram
Memory Speed: 667 Mhz
Memory Specification Compliance: Pc2-5300
Form Factor: Fb-Dimm 240-Pin
Features: Fully Buffered
Configuration Features: 4 X 2 Gb
Storage:
Hard Drive: Not Included
Optical Storage: Not Included
Storage Controller:
Storage Controller Type: 1 X Raid – Integrated
Controller Interface Type: Serial Ata-150 / Sas
Storage Controller Name: Smart Array P400i
Raid Level: Raid 0, Raid 5, Raid 10
Buffer Size: 256 Mb
Display & Graphics:
Graphics Controller: Integrated Ati Rn-50 32mb Ddr1
Network & Communication:
Networking: Network Adapter – Pci Express X4 – Integrated
Ethernet Ports: 4 X Gigabit Ethernet
Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
Features: Wake On Lan (Wol)
Compliant Standards: Ieee 802.3, Ieee 802.3u, Ieee 802.3ab
Expansion And Connectivity:
Expansion Bays Total (Free):
2 ( 2 ) X Hot-Swap – 2.5 Sff (2 Bays)
Expansion Slots Total (Free):
2 ( 0 ) X Processor
16 ( 12 ) X Memory – Fb-Dimm 240-Pin
3 ( 3 ) X Expansion Slot
Interfaces/Ports:
1 X Management – Hp Ilo – Rj-45
4 X Network – Rj-45
1 X Display / Video – 15 Pin Hd D-Sub (Hd-15)
