GENERAL INFORMATION :
Manufacturer : Dell
Manufacturer Part Number : 463-5896
Product Name: Poweredge R720 13th Gen – 5u Tower Server
PROCESSOR & CHIPSET :
CPU : Intel Xeon E5-2620V3 / 2.4 GHz
Max Turbo Speed : 3.2 GHz
Number Of Cores : 6-Core
Cpu Qty : 1
Max Cpu Qty : 2
Cpu Upgradability : Upgradable
Processor Main Features : Intel Turbo Boost Technology 2
Chipset Type : Intel C610
CACHE MEMORY :
Cache Memory Type : Smart Cache
Installed Size : 15 MB
Cache Per Processor : 15 MB
MEMORY :
Installed Size : 8 GB / 384 GB (MAX)
Technology : DDR4 SDRAM
Memory Speed : 2133 MHz
Form Factor : DIMM 288-PIN
Configuration Features : 1 X 8 GB
Memory Slots: 24 x DDR4 RAM Slots
STORAGE:
Hard drive :
Type : HDD – Hot-Swap
Capacity : 1 X 300 GB
Interface Type : SAS 6GB/S
Spindle Speed : 10000 RPM
Optical Drive : DVD-ROM – SATA
STORAGE CONTROLLERS:
Type : 1 X RAID
Controller Interface Type : SAS 12GB/S
Storage Controller Name : DELL PERC H730
Channel Qty : 2
Raid Level : RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60
Buffer Size : 1 GB
DISPLAY & GRAPHICS CONTROLLERS :
Type : Integrated
Graphics Processor : Matrox G200
Video Memory : 16 MB
Video Interfaces : VGA
NETWORK & COMMUNICATION:
Ethernet Ports : 2 X Gigabit Ethernet
Ethernet Controller : Broadcom Bcm5720
Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller : Integrated Dell Remote Access Controller 8 Enterprise (IDRAC8)
POWER DESCRIPTION :
Device Type : Power Supply – Hot-Plug / Redundant
Power Redundancy : Yes
Power Redundancy Scheme : 1+1
Installed Qty : 1
Max Supported Qty : 2
Nominal Voltage : AC 120/230 V ( 50/60 HZ )
Power Provided : 750 WATT
EXPANSION/ CONNECTIVITY :
Expansion bays total (free) :
8 (Total) / 7 (Free) X Hot-Swap 2.5
EXPANSION SLOTS TOTAL (FREE) :
2 PCIE 3.0 X16 – FULL-LENGTH, FULL-HEIGHT
1 PCIE 2.0 X4 – FULL-LENGTH, FULL-HEIGHT
1 PCIE 3.0 X8 – HALF-LENGTH, FULL-HEIGHT
2 (TOTAL) / 1 (FREE) X CPU
24 (TOTAL) / 23 (FREE) X DIMM 288-PIN
INTERFACES & PORTS :
4 X USB 2.0
3 X USB 3.0 ( 1 FRONT, 2 REAR )
2 X VGA ( 1 FRONT, 1 REAR )
1 X SERIAL
2 X LAN (GIGABIT ETHERNET)
1 X MANAGEMENT (NIC)
