General Information :
Manufacturer : Hewlett Packard
Manufacturer Part Number : 648256-001
Product Name : Proliant Dl380e G8 2u Rack Mount Entry Model
Processor & Chipset :
Processor Type : Intel Xeon E5-2403 /1.8ghz
Number Of Cores : Quad-Core (4 Core)
Sockets Supported : Lga1356
64-Bit Computing : Yes
Installed Qty : 1
Max Supported Qty : 2
Upgradability : Upgradable
Processor Main Features :
Hyper-Threading Technology,
Intel Quick path Interconnect,
Chipset Type : Intel C600
Cache Memory :
Cache Memory Type : L3 Cache
Installed Size : 10 Mb
Cache Per Processor : 10 Mb
Memory :
Installed Size : 4 Gb
Maximum Size : 384 Gb
Technology : Ddr3 Sdram
Memory Speed : 1333 Mhz
Memory Specification Compliance : Pc3-10600
Form Factor : Dimm 240-Pin
Features : Load-Reduced Dimm (Lrdimm)
Configuration Features : 1 X 4 Gb
Total Memory Slots : 12 Ddr3 Slots
Storage & Storage Controller :
Hard Drive : None Ship Standard, Includes 8 Sff Hard Drive Blanks
Internal Storage : 8 Sff Hdd 8 Bays
Storage Controller Type : 1 X Serial Attached Scsi 2 Integrated – Pci Express X4
Controller Interface Type : SAS Serial Attached Scsi 2.0
Storage Controller Name : Hp Dynamic Smart Array B320i With 512mb Fbwc
Channel Qty : 8
Raid Level : Raid 0, Raid 1, Raid 5, Raid 10,
Buffer Size : 512 Mb
Display & Graphics Controllers :
Graphics Controller Type : Integrated
Graphics Processor : Matrox G200
Graphics Regulation :
1280 X 1024 (32 Bpp)
1920 X 1200 (16 Bpp)
Network & Communication :
Networking : Network Adapter – Pci Express 2.0 X2 – Integrated
Ethernet Ports : 4 X Gigabit Ethernet
Ethernet Controller(S) : Hp Ethernet 1gb 4-Port 366i Adapter
Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller : Integrated Lights-Out 4
Features : Wake On Lan (Wol), Pxe Support
Compliant Standards : Ieee 802.3, Ieee 802.3u, Ieee 802.3ab, Ieee 802.1as, Ieee 802.3az
Expansions & Connectivity :
Expansion Bays Total (Free) :
8 (Total) / 8 (Free) X Hot-Swap 2.5in Sff
1 (Total) / 1 (Free) X External
Expansion Slots Total (Free) :
12 (Total) / 11 (Free) X Memory – Lrdimm 240-Pin
2 (Total) / 1 (Free) X Processor
1 (Total) / 1 (Free) X Pcie 3.0 X8 – Full-Length, Full-Height ( X4 Mode )
1 (Total) / 1 (Free) X Pcie 3.0 X16 – Half-Length, Full-Height ( X8 Mode )
1 (Total) / 1 (Free) X Pcie 3.0 X8 – Half-Length, Full-Height
1 (Total) / 1 (Free) X Pcie 2.0 X8 – Low-Profile ( X4 Mode )
1 (Total) / 1 (Free) X Sd Card
Interfaces & Ports :
2 X Display / Video ( 1 Front, 1 Rear )
4 X Network – Ethernet 10base-T/100base-Tx/1000base-T – Rj-45
1 X Management – Hp Ilo – Rj-45
7 X Hi-Speed Usb – 4 Pin Usb Type A ( 2 Front, 4 Rear )
1 X Serial
Power Device :
Device Type : Power Supply – Hot Plug
Power Redundancy : Yes
Power Redundancy Scheme : 1+1
Installed Qty : 1
Max Supported Qty : 2
Voltage Required : Ac 120/230 V ( 50/60 Hz )
Power Provided : 460 Watt
80 Plus Certification : 80 Plus Platinum
