GENERAL INFORMATION :
Manufacturer : Hewlett Packard
Manufacturer Part Number : 704558-001
Product Name : Proliant Dl380p Gen8 – 2-Way 2u Rack Mount (25sff Model)
PROCESSOR & CHIPSET :
Processor Type : Intel Xeon E5-2650v2 / 2.6ghz
Number Of Cores : 8
64-Bit Computing : Yes
Installed Qty : 2
Max Supported Qty : 2
Upgradability : Upgradable
Chipset Type : Intel C600
CACHE MEMORY :
Cache Memory Type : L3 Cache
Installed Size : 40 Mb
Cache Per Processor : 20 Mb
MEMORY :
Installed Size : 32 Gb
Maximum Size : 384 Gb
Technology : Ddr3 Sdram
Form Factor : Dimm 240-Pin
STORAGE & STORAGE CONTROLLER :
Hard Drive : None
Optical Drive Type : None
Card Reader Type : Card Reader
Supported Flash Memory Cards : Sd Memory Card
Storage Controller Type : 1 X Raid – Integrated – Pci Express 3.0 X8
Controller Interface Type : Sata 6gb/S / Sas 6gb/S
Storage Controller Name : Smart Array P420i With 2gb Fbwc
Raid Level : Raid 0, Raid 1, Raid 5, Raid 10, Raid 50
Buffer Size : 2 Gb
DISPLAY & GRAPHICS CONTROLLERS :
Graphics Controller Type : Integrated
Graphics Processor : Matrox G200
NETWORK & COMMUNICATION :
Networking : Plug-In Card Pci Express X4
Ethernet Ports : 2 X 10 Gigabit Ethernet
Ethernet Controller(S) : Hp 533flr-T
Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet
Remote Management Controller : Integrated Lights-Out 4
Compliant Standards : Ieee 802.3, Ieee 802.3x, Ieee 802.3ad (Lacp), Ieee 802.1ax, Ieee 802.1qbb, Ieee 802.1qaz, Ieee 802.1qau, Ieee 802.1qbg, Ieee 802.2x
POWER DEVICE :
Device Type : Power Supply – Hot Plug
Power Redundancy : Optional
Power Redundancy Scheme : 1+1 (With Optional Power Supply)
Installed Qty : 2
Max Supported Qty : 2
Nominal Voltage : Ac 120/230 V ( 50/60 Hz )
Power Provided : 750 Watt
80 Plus Certification : 80 Plus Platinum
