GENERAL INFORMATION :
Manufacturer : Hewlett Packard
Manufacturer Part Number : 724088-B21
Product Name : Proliant Bl460c Gen8 – 2 Way Blade Server
PROCESSOR & CHIPSET :
Processor Type : Intel Xeon E5-2650lv2 / 1.7 Ghz
Number Of Cores : 10 Core
64-Bit Computing : Yes
Installed Qty : 1
Max Supported Qty : 2
Upgradability : Upgradable
Chipset Type : Intel C600
CACHE MEMORY :
Cache Memory Type : L3 Cache
Installed Size : 25mb
Cache Per Processor : 25mb
MEMORY :
Installed Size : 32 Gb (2 X 16 Gb)
Maximum Size : 256 Gb
Technology : Ddr3 Sdram
Memory Speed : 1600 Mhz
Memory Specification Compliance : Pc3-12800
Form Factor : Dimm 240-Pin
RAM SUPPORTED :
Pc3-14900 – 256 Gb – Registered
Pc3-14900 – 128 Gb – Unbuffered – Advanced Ecc
Pc3-14900 – 512 Gb – Low Voltage – Load-Reduced
STORAGE & STORAGE CONTROLLER :
Hard Drive : None
Optical Drive Type : None.
Card Reader Type : Card Reader
Supported Flash Memory Cards : Microsdhc
Storage Controller Type : 1 X Sas-2 – Integrated – Pci Express X4
Controller Interface Type : Sas 6gb/S
Storage Controller Name : Smart Array P220i With 512mb Fbwc
Raid Level : Raid 0, Raid 1
Buffer Size : 512 Mb
DISPLAY & GRAPHICS CONTROLLERS :
Graphics Controller Type : Integrated
Graphics Processor : Matrox G200
NETWORK & COMMUNICATION :
Networking : Plug-In Card Pci Express 2.0 X8
Ethernet Ports : 2 X 10 Gigabit Ethernet
Ethernet Controller(S) : Hp 554flb
Data Link Protocol : Gigabit Ethernet, 10 Gigabit Ethernet, Fibre Channel Over Ethernet (FCoE)
Remote Management Protocol : Snmp, Ipmi 2.0, Smash Clp
Remote Management Controller : Integrated Lights-Out 4
Features : Wake On Lan (Wol)
Compliant Standards : Ieee 802.1q, Ieee 802.1p, Ieee 802.3x, Ieee 802.3ad (Lacp), Ieee 802.3ae, Ieee 802.3ap
